Titan 4 Post Car Lift

General Information

The Titan 4 Post Car Lift is the most economical way to instantly double your parking capacity! SUV model also available (80″ lifting height). Easy to install and virtually maintenance-free.

Power Unit

110v 1hp 30amp Standard
220v 2hp 30 amp High-Speed

Quality

3.5″ Cylinder/.5″ Steel Plate
Made in USA

Models

Special narrow and
SUV models available

Warranty

5-years Mechanical
1-year Parts/Electrical

Product Information

  • BALL BEARING IN PULLEY:  The TITAN LIFT uses ball bearing pulleys that are designed for commercial applications.
  • NON-SAG ROUNDED EDGED DIAMOND PLATE STEEL TRACKS
  • RUSTPROOF DRIP PANS: Three FREE with your TITAN purchase. Pans fit snugly between tracks to catch oil/fluid drips from vehicle above. Ultra-lightweight for easy removal.
  • LIGHTWEIGHT ALUMINUM RAMPS: One pair free with your TITAN LIFT. Ultra-low (4” high x 36” long) profile accommodates even the lowest-riding vehicles! Each ramp weighs only 16 lbs. for easy removal (steel ramps weigh 45 lbs.).
  • EXTRA WHEEL STOPS INCLUDED: Simply replace the removable ramps with these stops for safe long-term storage.
  • PLENTY OF LIFTING HEIGHT: Accommodates virtually all sport utility vehicles and mini vans. Ample headroom for doing underbody work. Std model: 67” clearance on top lock. SUV model: 77” clearance on top lock.
  • TEN DIFFERENT LOCKING POSITIONS: Locks are positioned at approximately 4 3/8” apart, allowing you to choose the lifting height that best fits your needs.
  • HEAVY DUTY POWER UNIT: 110V or 220v power unit at no additional cost.
  • 3½” DIAMETER CYLINDER: Smaller cylinders may be overworked and prone to leakage.
  • ½ GAUGE BASEPLATE: Most other lift companies use a 3/8” gauge base plate. These tend to warp when welded to the columns when cooling, thus causing lift to rest uneven on foundation. With the TITAN LIFT ½ gauge base-plate, the lift will always rest flush which prevents the lift from swaying.
  • POWDER-COAT FINISH FOR INDOOR/OUTDOOR USE: Your choice of red, white, blue or black. Custom colors also available for an extra charge.
  • HEAVY GAUGED AIRCRAFT QUALITY CABLES: Lift operates on four independent cables rated at 14,500 lbs. each (58,000 lb. combined cable-load capacity).
  • EASY INSTALLATION: Do it yourself or use our nationwide professional installation service
  • JACK TRAY: For use with bottleneck jacks for doing wheel/brake work – Call for Pricing
  • ELECTRIC LOCK RELEASE: Allows you to simply disengage all four locks by a push of a button. No need to hold down the single point lock release level – Call for Pricing
  • CASTERS WITH NEOPRENE-COATED WHEELS: To make the lift portable so you can move it around – Call for Pricing
  • SET OF TWO REMOVABLE SOLID CENTERS: Enables you to store bikes, lawnmowers, boxes, etc. Steel | Lightweight Aluminum: Call for Pricing
  • EXTRA DRIP PANS: (Optional: Powder coat steel drip pans – Call for Pricing)
  • EXTRA ALUMINUM RAMPS: Call for Pricing – With exchange for steel ramps

Titan 4 Post Lift Specifications

Product Downloads:

Titan 4 Post Lift Brochure
